Standard Exporting of Events

Zeta Marketing Platform generates a standard event export for campaign events. This document specifies the export layout, output format, output location, and custom configuration option.

Alternatively, for clients who have the ability to access data directly from Snowflake, we can expose a Read-Only Snowflake Data Share of these events with the same layout. Note that this may incur additional annual costs to maintain. For more details on Snowflake Data Sharing, please visit Snowflake's documentation.

Event Data Layout

Field	Type	Description/Logic
event_type	String	Type of the event, including the below values: campaign_sent campaign_opened campaign_clicked campaign_bounced campaign_unsubscribed campaign_complaint campaign_converted campaign_delivered campaign_skipped recommendation_request recommendation_served recommendation_viewed recommendation_clicked user_updated segment_entry segment_exit imh_reply All other values of event_type that are specific per account should be delivered as they were sent.
event_id	String	Unique identifier for this event.
site_id	String	Site for which the event was served.
resource_type	String	The type of resource acted upon in the event. Expected for: Most Analyticstrain events (especially {{viewed}} events) bt_rec_view bt_rec_click bt_rec_served
resource_id	String	The identifier for resource acted upon in the event. Expected for: Most Analyticstrain events (especially {{viewed}} events) bt_rec_view bt_rec_click bt_rec_served
event_time	String	ISO-8601 String representation of the time of the event
recset	String	Identifier for a set of recommendations. Expected for: bt_recset_request bt_rec_served bt_rec_view bt_rec_click
rec_group	String	Identifier for the group in the recommendation set. Expected for: bt_rec_served bt_rec_view bt_rec_click
rec_position	Number	Identifier for the position of the recommendation in the recommendation set. Expected for: bt_rec_served bt_rec_view bt_rec_click
campaign_name	String	Human-readable name of the campaign. Derived from campaign name for: campaign_sent campaign_opened campaign_clicked campaign_bounced campaign_unsubscribed campaign_complaint campaign_converted campaign_delivered campaign_skipped imh_reply Derived from "properties.campaign" for bt_recset_request bt_rec_served bt_rec_clicked
campaign_id	String	A machine-readable identifier for the campaign. Only present for the following events: campaign_sent campaign_opened campaign_clicked campaign_bounced campaign_unsubscribed campaign_complaint campaign_converted campaign_delivered campaign_skipped imh_reply
channel	String	The campaign channel for this campaign. Possible values are: email sms push webhook onsite For personalized recommendations from the ML system, use the "medium" specified for the recommendation set. Expected for: bt_recset_request
campaign_tags	List	In JSON or JSONL format, the value should be an array of strings, each one representing a tag, e.g. "campaign_tags":["Tag_1", "Tag_2", "Tag_3"]. In {{CSV}} format, a delimited string representing this list is used, e.g.: "[""Tag_1"",""Tag_2"",""Tag3""]" Only present for the following events: campaign_sent campaign_opened campaign_clicked campaign_bounced campaign_unsubscribed campaign_complaint campaign_converted campaign_delivered campaign_skipped imh_reply
campaign_codes	Stringified JSON Object	A stringified JSON Object representing the external campaign code key:value pairs specified for this message that are not tracking codes used on liks. This may include an external campaign or segment key. Only present for the following events: campaign_sent campaign_skipped campaign_opened campaign_clicked campaign_bounced campaign_unsubscribed campaign_complaint campaign_converted campaign_delivered campaign_skipped imh_reply
campaign_tracking_codes	Stringified JSON Object	A stringified JSON Object representing the "external tracking" key:value pairs specified for this message and appended to links. This may include Google Analytics or custom tracking specified in the Create Campaign flow. Only present for the following events: campaign_sent campaign_opened campaign_clicked campaign_bounced campaign_unsubscribed campaign_complaint campaign_converted campaign_delivered campaign_skipped imh_reply
campaign_type	String	The type of campaign (e.g. {{"broadcast", "trigger", "file_drop"}}) Only present for the following events: campaign_sent campaign_opened campaign_clicked campaign_bounced campaign_unsubscribed campaign_complaint campaign_converted campaign_delivered campaign_skipped imh_reply
message_uid	String	Unique identifier for the communication that is sent.  Only present for the following events: campaign_sent campaign_opened campaign_clicked campaign_bounced campaign_unsubscribed campaign_complaint campaign_converted campaign_delivered imh_reply
subject_line	String	The subject line of the actual email message sent for email channel campaign events. Expected for: campaign_sent campaign_opened campaign_clicked campaign_bounced campaign_unsubscribed campaign_complaint campaign_converted campaign_delivered campaign_skipped imh_reply
batch	String	The specific batch for the campaign.
email	String	The email address of the user at the time of the event, if known.
user_id	String	The user_id or uid of the user at the time of the event, if known.
geo_subdivision	String	The enriched subdivision (e.g. state/province) derived by Events Service for the event.
geo_country	String	The enriched country derived by Events Service for the event.
geo_city	String	The enriched city derived by Events Service for the event.
geo_latitude	Float	The enriched latitude derived by Events Service for the event.
geo_longitude	Float	The enriched longitude derived by Events Service for the event.
user_agent	String	The user agent string from the browser of the user.
browser_name	String	The name of the client/browser for which an email was opened or clicked, or an event was tracked.
browser_version	String	The version of the browser for which an email was opened or clicked, or an event was tracked.
os_name	String	The name of the operating system for which an email was opened or clicked, or an event was tracked.
os_version	String	The version of the operating system for which an email was opened or clicked, or an event was tracked.
device_type	String	The name of the device type for which an email was opened or clicked, or an event was tracked.
url	String	The URL of the link clicked or the page viewed.
original_url	String	The redirected URL if there is any.
session	String	A session derived by Analyticstrain for the user session. p13n session_id lasts for an hour of no activity. If an user performs any activity(that results in reloading/initializing p13n on the site) within that hour, the session_id ‘s expiry will be extended by an hour. For example,
properties	JSON Object	A stringified JSON Object representing the properties specified in the event. Derived from stringifying "properties" on all events.
user_attributes	JSON Object	A JSON list representing the user attributes of the user at the time of the event that are configured via the user_attribute_whitelist setting. Note that this field will be empty if the user_attribute_whitelist is unset or empty.
scoped_user_attributes	JSON Object	A JSON list representing the all the child specific/scoped attributes (across ALL children) for a parent site enabled for sub account structure.
file	Stringified JSON Object	A stringified JSON Object representing the file columns specified in a File Drop Triggered Campaigns campaign for this message.
version_name	String	Version name of the multi-version campaign. Only present for the following events: campaign_sent campaign_opened campaign_clicked campaign_bounced campaign_unsubscribed campaign_complaint campaign_converted campaign_delivered campaign_skipped imh_reply
abtest_version	String	Version name of AB test. Only present for the following events: campaign_sent campaign_opened campaign_clicked campaign_bounced campaign_unsubscribed campaign_complaint campaign_converted campaign_delivered campaign_skipped imh_reply

Export Output Formats

The output of the above events can be either a JSON, JSONL, or a CSV file.

For CSV files, nested objects will be added into the single column.

CSV: CSV files will be delivered with a column header indicating the fields in the event schema above.

JSON: For JSON files, all fields in the event schema noted above that are "Stringified JSON" should be instead expressed as JSON objects.

JSONL: For JSONL files, all fields in the event schema noted above that are "Stringified JSON" should be instead expressed as JSON objects. Note that each record will be delivered as its own JSON object.

Export Data File Generation

Files will be generated and dumped on a daily or hourly basis, selecting events that were processed by the Zeta Event Service within the given hour or day window.

For daily dumps, filename should be  {{events_YYYYMMDD-PARTITIONNUM}}, e.g. {{events_20180120-0}}.

For hourly dumps, filename should be  {{events_YYYYMMDDHH24h-PARTITIONNUM}}, e.g. {{events_2018012013h-0}}.

Export Data Output Location

FTP: Files will be placed in an FTP location, authorized for access with the customer's FTP Token, at the following locations:

Hourly Data

ftp://ftp.boomtrain.net/<site_id>/data/events/hourly/<config_id>

Hourly files are created on the 50th minute for the hour prior; i.e. for events from 9 am to 10 am, the file will be generated around 10:50 am.

Daily Data

ftp://ftp.boomtrain.net/<site_id>/data/events/daily/<config_id>

Data Retention

Both Daily and Hourly files are automatically removed from the file server after 30 days.

Additional File Format

File name and path will be the same original report, the only difference is file extension i.e., cnt
Fields present in the .cnt file mentioned below

Filed Name	Description
export_timestamp	Start time of hourly or daily report generation.
export_path	File name and the location.
num_rows	Number of rows in the record.
start_etl_time	Start time of events included in the report, events etl_time greater than equal to will be considered in the report.
end_etl_time	End time of events included in the report,  events etl_time less than will be considered in the report.

Sample File

// events_2019021422h.cnt

{

   "export_timestamp": "2019-02-14T23:50:30+0000"

   "export_path": "default/events_2019021422h.json",

   "num_rows": 12212,

   "start_etl_time": "2019-02-14T22:00:00+0000",

   "end_etl_time": "2019-02-14T22:59:59+0000"

}
